CX

Solar Gard’s ceramic products leverage solar absorbing technology to provide high heat rejection without sacrificing views.

Key Benefits

  • Advanced sputtered ceramic technology rejects up to 58% of total solar energy resulting in improved indoor climate control and total comfort
  • Low visible reflectivity provides uncompromising views to the outside while maintaining the natural appearance of the exterior
  • Exceptional durability makes it optimal for use in demanding coastal environments
  • UV blockers protect people and property from damaging UV rays



Specification CX 35CX 50CX 60
Visible light transmittance % 37%50%61%
Visible light reflectance (exterior) % 16%13%11%
Visible light reflectance (interior) % 15%11%9%
Solar heat gain coefficient .42.52.60
Total solar energy rejected % 58%48%40%
UV Tdw-ISO @ 300 to 700 nm % 25%33%40%
UV light blocked (300 to 380 nm) % >99%>99%>99%
Fade Reduction % 70%60%51%

Performance Notes:

  • Performance results are calculated using NFRC methodology and LBNL Window software, applied to 1/4" (6mm) clear glass and are subject to variations within industry standards and only intended for estimating purposes. This data is provided for informational purposes only and subject to normal manufacturing variances.
  • Performance results for glare and fade reduction are calculated by comparing filmed glass to that of untreated glazing.

CSI Specifications: Solar Control Films 08 87 13
