Clear Safety

Optically clear, colourless and undetectable on glass, Armorcoat® safety films maintain the natural appearance of your windows day or night. The resilient layers of high-tensile polyester and aggressive adhesives provide exceptional impact resistant capabilities.

Key Benefits

  • Deters unwanted intruders from home or business
  • Reduces the likelihood of injury from flying glass
  • Virtually invisible maximising your view through the windows
  • Protect people and property from damaging UV rays
Specification Armorcoat-Clear 10milArmorcoat-Clear 11milArmorcoat-Clear 14milArmorcoat-Clear 4milArmorcoat-Clear 7milArmorcoat-Clear 8mil
Visible light transmittance % 86%86%87%88%88%88%
Visible light reflectance (exterior) % 11%11%10%9%9%9%
Visible light reflectance (interior) % 11%11%10%9%9%9%
Solar heat gain coefficient .78.78.78.79.79.79
Total solar energy rejected % 22%22%22%21%21%21%
UV Tdw-ISO @ 300 to 700 nm % 61%61%62%63%63%63%
UV light blocked (300 to 380 nm) % >99%>99%>99%>99%>99%>99%
Fade Reduction % 26%26%24%23%23%23%

Performance Notes:

  • Performance results are calculated using NFRC methodology and LBNL Window software, applied to 1/4" (6mm) clear glass and are subject to variations within industry standards and only intended for estimating purposes. This data is provided for informational purposes only and subject to normal manufacturing variances.
  • Performance results for glare and fade reduction are calculated by comparing filmed glass to that of untreated glazing.

CSI Specifications: Safety and Security Films 08 87 23
